Features :
- Impulsive power with both channels driven:
- 2 x 170W (8 ohm)
- 2 x 320W (4 ohm)
- Continuous power with both channels driven
- 2 x 150W (8 ohm)
- 2 x 200W (4 ohm)
- XLR-F input sockets and Jacks for “link” connections
- Power outputs with Speakon connectors (min 4 ohm)
- Power output in Bridge mode with Speakon connector (min 8 ohm)
- 3-way switch to select operating mode: Parallel, Stereo or Bridge
- 3-way switch to select the Butterworth filter operating mode: By-Pass,
- High-Pass or Low-Pass
- Switch to select the high-pass cutoff frequency 35 Hz or 120 Hz
- Power supply protection with miniature circuit breaker
- Delayed output connection
- DC protection for speakers (relays)
- Short-circuit protection
- Operating mode indicator LEDs
- Fast Recovery Clipping function
- Frequency response 20Hz – 20kHz
- Dimensions (WxHxD) 482x88x410 mm
- Weight 13.2 kg
Click Here to Download fbt-power-amplifier-hp600 PDF
